barman

Site officiel : https://pgbarman.org/

Voir aussi : pgBackRest, wal-g.


Journaux liées à cette note :

Journal du jeudi 13 février 2025 à 14:50 #backup, #postgresql, #L15, #L1

Suite à ce commentaire et celui-ci, je m'adresse dans cette note à Anarcat (francophone) et Martín Marqués pour expliquer ce que j'essaie de faire dans le POC https://github.com/stephane-klein/poc-barman, ce que j'ai réussi à faire et présenter aussi mes difficultés.

J'ai traduit cette note en anglais et je l'ai postée sur "GitHub Barman discussion" : https://github.com/EnterpriseDB/barman/discussions/1067.


Mon objectif dans le repository poc-barman est d'essayer d'utiliser barman dans un container Docker sidecar pour sauvegarder un container PostgreSQL.

Une de mes contraintes est d'effectuer un minimum de changements au niveau du container PostgreSQL que je souhaite sauvegarder. Je souhaite pouvoir utiliser une image Docker PostgreSQL mainstream https://hub.docker.com/_/postgres, sans changement.

Je souhaite utiliser le mode de sauvegarde de barman nommé streaming backups method: backup_method = postgres qui se base sur la commande pg_basebackup (commande officielle intégrée à PostgreSQL).

Je souhaite utiliser la nouvelle fonctionnalité pg_basebackup --incremental... de la version 17 de PostgreSQL.

Voici ma configuration de barman : https://github.com/stephane-klein/poc-barman/blob/4df58ecc5af6d2d1f7607c364400f8c5ba012496/docker-compose.yml#L15

Et voici ma configuration de PostgreSQL 17 :

J'ai implémenté un script nommé ./scripts/reset.sh qui effectue un test de bout automatiquement.

Voici son screencast :

Voici ce qu'il fait :

Questions que je me pose :

  • Pourquoi la restauration basée sur la sauvegarde incrémentielle échoue ?
  • Est-ce que mon scénario de test d'usage de barman est correct, est-ce qu'il me manque des étapes ou est-ce que je fais des opérations non nécessaires ?
  • Est-ce que j'ai fait des erreurs importantes ?

Voici ci-dessous la version anglaise posté ici.


Subject: Streaming Incremental Backup Configuration with PostgreSQL 17 using Docker Sidecar

Hello,

In the poc-barman repository, I'm trying to use barman in a Docker sidecar container to backup a PostgreSQL container.

One of my constraints is to make minimal changes to the PostgreSQL container that I want to backup. I want to be able to use a mainstream Docker PostgreSQL image https://hub.docker.com/_/postgres, without modifications.

I want to use the barman backup mode called streaming backups method: backup_method = postgres which is based on the pg_basebackup command (official command integrated into PostgreSQL).

I want to use the new pg_basebackup --incremental... feature from PostgreSQL version 17.

Here is my barman configuration: https://github.com/stephane-klein/poc-barman/blob/4df58ecc5af6d2d1f7607c364400f8c5ba012496/docker-compose.yml#L15

And here is my PostgreSQL 17 configuration:

I implemented a script called ./scripts/reset.sh that performs an end-to-end test automatically.

Here's its screencast:

Here's what it does:

Questions:

  • Why does the restoration based on the incremental backup fail?
  • Is my barman usage test scenario correct, am I missing steps or am I performing unnecessary operations?
  • Have I made any significant mistakes?

Best regards,
Stephane

Journal du jeudi 13 février 2025 à 14:09 #postgresql, #backup

Suite de mes notes 2025-02-09_1705, 2025-02-12_1044, 2025-02-12_1511, 2025-02-12_1534 et 2025-02-12_2305 au sujet de barman pour sauvegarder des bases de données PostgreSQL


Je ne sais pas pourquoi je dois lancer select pg_switch_wal();.

source

J'ai découvert dans ce commentaire qu'il existe une commande nommée : barman switch-wal.

Je pense avoir compris qu'avant d'exécuter barman backup… il est nécessaire d'exécuter :

$ barman switch-wal
$ barman cron
$ barman check postgres1
Server postgres1:
        PostgreSQL: OK
        superuser or standard user with backup privileges: OK
        PostgreSQL streaming: OK
        wal_level: OK
        replication slot: OK
        directories: OK
        retention policy settings: OK
        backup maximum age: OK (no last_backup_maximum_age provided)
        backup minimum size: OK (0 B)
        wal maximum age: OK (no last_wal_maximum_age provided)
        wal size: OK (0 B)
        compression settings: OK
        failed backups: OK (there are 0 failed backups)
        minimum redundancy requirements: OK (have 0 backups, expected at least 0)
        pg_basebackup: OK
        pg_basebackup compatible: OK
        pg_basebackup supports tablespaces mapping: OK
        systemid coherence: OK (no system Id stored on disk)
        pg_receivexlog: OK
        pg_receivexlog compatible: OK
        receive-wal running: OK
        archiver errors: OK

$ barman backup postgres1 --immediate-checkpoint
Starting backup using postgres method for server postgres1 in /var/lib/barman/postgres1/base/20250213T100353
Backup start at LSN: 0/4000000 (000000010000000000000004, 00000000)
Starting backup copy via pg_basebackup for 20250213T100353
Copy done (time: 1 second)
Finalising the backup.
This is the first backup for server postgres1
WAL segments preceding the current backup have been found:
        000000010000000000000002 from server postgres1 has been removed
Backup size: 22.3 MiB
Backup end at LSN: 0/6000000 (000000010000000000000006, 00000000)
Backup completed (start time: 2025-02-13 10:03:53.072228, elapsed time: 1 second)
Processing xlog segments from streaming for postgres1
        000000010000000000000003
        000000010000000000000004
WARNING: IMPORTANT: this backup is classified as WAITING_FOR_WALS, meaning that Barman has not received yet all the required WAL files for the backup consistency.
This is a common behaviour in concurrent backup scenarios, and Barman automatically set the backup as DONE once all the required WAL files have been archived.
Hint: execute the backup command with '--wait'
total 4.0K
$ ls /var/lib/barman/postgres1/base/ -lha
total 8.0K
drwxr-xr-x 1 barman barman 60 Feb 13 10:00 .
drwxr-xr-x 1 barman barman 88 Feb 13 09:59 ..
drwxr-xr-x 1 barman barman 30 Feb 13 09:59 20250213T095917

$ barman list-backups postgres1
postgres1 20250213T103723 - F - Thu Feb 13 10:37:24 2025 - Size: 22.3 MiB - WAL Size: 0 B - WAITING_FOR_WALS

J'ai réussi dans le POC https://github.com/stephane-klein/poc-barman à dérouler toutes les étapes du backup complet jusqu'à la restauration d'une base de données.

Toutefois, pour le moment, je n'ai toujours pas réussi à restaurer un backup incrémental 🙁.

À cet endroit, j'ai l'erreur suivante :

$ docker compose up postgres2
postgres2-1  | PostgreSQL Database directory appears to contain a database; Skipping initialization
postgres2-1  |
postgres2-1  | 2025-02-13 13:20:07.594 UTC [1] LOG:  starting PostgreSQL 17.2 (Debian 17.2-1.pgdg120+1) on x86_64-pc-linux-gnu, compiled by gcc (Debian 12.2.0-14) 12.2.0, 64-bit
postgres2-1  | 2025-02-13 13:20:07.594 UTC [1] LOG:  listening on IPv4 address "0.0.0.0", port 5432
postgres2-1  | 2025-02-13 13:20:07.594 UTC [1] LOG:  listening on IPv6 address "::", port 5432
postgres2-1  | 2025-02-13 13:20:07.596 UTC [1] LOG:  listening on Unix socket "/var/run/postgresql/.s.PGSQL.5432"
postgres2-1  | 2025-02-13 13:20:07.598 UTC [1] LOG:  could not open directory "pg_tblspc": No such file or directory
postgres2-1  | 2025-02-13 13:20:07.600 UTC [29] LOG:  database system was interrupted; last known up at 2025-02-13 13:20:03 UTC
postgres2-1  | 2025-02-13 13:20:07.643 UTC [29] LOG:  could not open directory "pg_tblspc": No such file or directory
postgres2-1  | 2025-02-13 13:20:07.643 UTC [29] LOG:  starting backup recovery with redo LSN 0/8000028, checkpoint LSN 0/8000080, on timeline ID 1
postgres2-1  | 2025-02-13 13:20:07.643 UTC [29] LOG:  could not open directory "pg_tblspc": No such file or directory
postgres2-1  | 2025-02-13 13:20:07.649 UTC [29] FATAL:  could not open directory "pg_tblspc": No such file or directory
postgres2-1  | 2025-02-13 13:20:07.651 UTC [1] LOG:  startup process (PID 29) exited with exit code 1
postgres2-1  | 2025-02-13 13:20:07.651 UTC [1] LOG:  aborting startup due to startup process failure
postgres2-1  | 2025-02-13 13:20:07.652 UTC [1] LOG:  database system is shut down

Journal du mercredi 12 février 2025 à 23:05 #backup, #postgresql

Suite de ma note 2025-02-12_1511.

J'ai passé 5h40 sur un POC de barman, mais je n'ai pas eu beaucoup plus de succès qu'avec pgBackRest. Décidément, ces outils ne m'aiment pas 😔.

Repository du POC : https://github.com/stephane-klein/poc-barman

La commande barman check streaming-server retourne le message WAL archive: FAILED (please make sure WAL shipping is setup). Pour fixer cette erreur, je dois faire les manipulations suivantes que je trouve bizarre :

$ ./scripts/enter-in-pg1.sh
postgres=# select pg_switch_wal();
 pg_switch_wal
---------------
 0/206A330
(1 row)

et ensuite :

$ docker compose exec barman bash
root@5482aa5f8420:/# su barman
barman@5482aa5f8420:/$ barman cron
Starting WAL archiving for server streaming-server
barman@5482aa5f8420:/$ barman check streaming-server
Server streaming-server:
        PostgreSQL: OK
        superuser or standard user with backup privileges: OK
        PostgreSQL streaming: OK
        wal_level: OK
        replication slot: OK
        directories: OK
        retention policy settings: OK
        backup maximum age: OK (no last_backup_maximum_age provided)
        backup minimum size: OK (0 B)
        wal maximum age: OK (no last_wal_maximum_age provided)
        wal size: OK (0 B)
        compression settings: OK
        failed backups: OK (there are 0 failed backups)
        minimum redundancy requirements: OK (have 0 backups, expected at least 0)
        pg_basebackup: OK
        pg_basebackup compatible: OK
        pg_basebackup supports tablespaces mapping: OK
        systemid coherence: OK (no system Id stored on disk)
        pg_receivexlog: OK
        pg_receivexlog compatible: OK
        receive-wal running: OK
        archiver errors: OK

Je ne sais pas pourquoi je dois lancer select pg_switch_wal();.

J'ai pourtant configuré checkpoint_timeout='60s' :

    command: >
      postgres
      -c wal_level=replica
      -c summarize_wal=on
      -c checkpoint_timeout='60s'
      -c max_wal_size='100MB'

Je pensais que ce paramètre effectuait la même action que pg_switch_wal(); mais je constate que non.

Aussi, je constate que je dois aussi lancer pg_switch_wal(); pour que la commande suivante se termine :

barman@5482aa5f8420:/$ barman backup streaming-server --wait
Starting backup using postgres method for server streaming-server in /var/lib/barman/streaming-server/base/20250212T221703
Backup start at LSN: 0/5000B40 (000000010000000000000005, 00000B40)
Starting backup copy via pg_basebackup for 20250212T221703
Copy done (time: 1 second)
Finalising the backup.
Backup size: 22.3 MiB
Backup end at LSN: 0/7000000 (000000010000000000000007, 00000000)
Backup completed (start time: 2025-02-12 22:17:03.190492, elapsed time: 1 second)
Waiting for the WAL file 000000010000000000000007 from server 'streaming-server'
Processing xlog segments from streaming for streaming-server
        000000010000000000000005
Processing xlog segments from streaming for streaming-server
        000000010000000000000006

Je ne comprends pas non plus pourquoi.

Journal du mercredi 12 février 2025 à 15:11 #backup, #docker, #postgresql, #JaiDécidé

Je pense comprendre que pgBackRest ne permet pas d'utiliser des INET sockets pour communiquer avec PostgreSQL.

Toutefois, je me dis que je pourrais partager le volume PGDATA avec le sidecar pgBackRest pour lui donner accès à l'Unix Socket du Streaming Replication Protocol 🤔.

source

Je viens de me rappeler que pgBackRest a une seconde contrainte qui semble l'empêcher de fonctionner en Docker sidecar :

Backing up a running PostgreSQL cluster requires WAL archiving to be enabled. Note that at least one WAL segment will be created during the backup process even if no explicit writes are made to the cluster.

pg-primary:/etc/postgresql/15/demo/postgresql.conf ⇒ Configure archive settings :

archive_command = 'pgbackrest --stanza=demo archive-push %p'
archive_mode = on
max_wal_senders = 3
wal_level = replica

source

Cela signifie que l'exécutable pgbackrest doit être installé dans l'image Docker PostgreSQL.

Cela me pose un problème parce que mon objectif est de pouvoir utiliser un système de sauvegarde en Docker sidecar sans avoir à utiliser une image Docker PostgreSQL modifiée.

Cette contrainte ne semble pas présente avec barman qui propose 3 méthodes de backup :

La méthode postgres utilise pg_basebackup et je pense qu'elle peut fonctionner en Docker sidecar.

#JaiDécidé d'explorer cette piste.

Journal du mercredi 12 février 2025 à 10:44 #PostgREST, #backup, #JaiDécouvert

En travaillant sur le projet Projet 23 - "Ajouter le support pg_basebackup incremental à restic-pg_dump-docker", j'ai découvert que PostgreSQL propose deux protocoles de communication :

Sans vraiment comprendre, en 2020, j'avais activé le protocole streaming replication dans ce POC postgresql-streaming-replication-playground. Mais je n'avais jamais pris conscience de l'existence de ce second protocole.

Les développeurs de PostgreSQL semblent avoir décidé de créer un second protocole parce qu'ils n'ont pas du tout le même objectif.
Streaming Replication Protocol est optimisé dans la transmission des WAL et des snapshots (copie de l'intégralité du dossier PGDATA).

Le protocole Streaming Replication Protocol est entre autres utilisé par pg_basebackup, barman, pgBackRest, ou Patroni.

Comment activer Streaming Replication Protocol ?

Les images Docker Postgres setup par défaut le fichier pg_hba.conf suivant :

# TYPE  DATABASE        USER            ADDRESS                 METHOD

# "local" is for Unix domain socket connections only
local   all             all                                     trust
# IPv4 local connections:
host    all             all             127.0.0.1/32            trust
# IPv6 local connections:
host    all             all             ::1/128                 trust
# Allow replication connections from localhost, by a user with the
# replication privilege.
local   replication     all                                     trust
host    replication     all             127.0.0.1/32            trust
host    replication     all             ::1/128                 trust
host all all all scram-sha-256

J'ai compris que par défaut, toutes ces lignes configurent l'accès au Frontend/Backend Protocol.
Seules les lignes qui contiennent replication configurent l'accès au Streaming Replication Protocol.

Pour permettre l'accès au Streaming Replication Protocol par réseau TCP/IP en dehors du container Docker il est nécessaire d'ajouter la ligne suivante :

host    replication     all             all                     scram-sha-256

Suite à cette découverte, j'ai repensé à :

Pour faire face à ce problème, j'ai exploré fin 2023 une solution basée sur pgBackRest : Implémenter un POC de pgBackRest.
Je suis plus ou moins arrivé au bout de ce POC mais je n'ai pas été satisfait du résultat.
Je n'ai pas réussi à configurer pgBackRest en "pure Docker sidecar".
De plus, j'ai trouvé la restauration du backup difficile à exécuter.

source

et je me suis demandé si mon échec de configuration de pgBackRest en Docker sidecar n'était pas seulement dû au fait que je n'avais pas activé Streaming Replication Protocol 🤔.

La réponse semble être "oui" et "non".

Je suis tombé sur l'issue suivante : pgbackrest with postgresql in docker.

The problem might be harder than you think unfortunately. If the pgBackRest process is running on the VM (docker host), it will try to connect to PG locally using the unix socket, not the tcp "localhost" connection.

source

Je pense comprendre que pgBackRest ne permet pas d'utiliser des INET sockets pour communiquer avec PostgreSQL.

Toutefois, je me dis que je pourrais partager le volume PGDATA avec le sidecar pgBackRest pour lui donner accès à l'Unix Socket du Streaming Replication Protocol 🤔.

Entre mon exploration de pg_basebackup, mes envies de tester barman et de continuer mon POC pgBackRest… je me dis que je ne suis pas encore au bout de ce Yak!.

Journal du dimanche 09 février 2025 à 17:05 #postgresql, #backup, #projet, #JaiDécidé

J'utilise depuis 2019 les containers Docker suivant en sidecar pour sauvegarder automatiquement et régulièrement directement un volume Docker et un volume PostgreSQL :

restic-pg_dump-docker est très pratique et facile d'usage, voici un exemple d'utilisation dans un docker-compose.yml :

    restic-pg-dump:
        image: stephaneklein/restic-pg_dump:latest
        environment:
            AWS_ACCESS_KEY_ID: "admin"
            AWS_SECRET_ACCESS_KEY: "password"
            RESTIC_REPOSITORY: "s3:http://minio:9000/bucket1"
            RESTIC_PASSWORD: secret
            POSTGRES_USER: postgres
            POSTGRES_PASSWORD: password
            POSTGRES_HOST: postgres
            POSTGRES_DB: postgres

    postgres:
        image: postgres:16.1
        environment:
            POSTGRES_USER: postgres
            POSTGRES_DB: postgres
            POSTGRES_PASSWORD: password
        ports:
            - "5432:5432"
        volumes:
            - ./volumes/postgres/:/var/lib/postgresql/data/
        healthcheck:
            test: ["CMD", "sh", "-c", "pg_isready -U $$POSTGRES_USER -h $$(hostname -i)"]
            interval: 10s
            start_period: 30s

Il suffit de configurer les paramètres d'accès à l'instance PostgreSQL à sauvegarder et ceux de l'Object Storage où uploader les backups. Rien de plus, 😉.
Pour plus de paramètres, voir la section Configuration du README.md.

Cependant, je ne suis pas totalement satisfait de restic-pg_dump-docker. Cet outil effectue seulement des sauvegardes complètes de la base de données.
Ceci ne pose généralement pas trop de problème quand la base de données est d'une taille modeste, mais c'est bien plus compliqué dès que celle-ci fait, par exemple, plusieurs centaines de mégas.

Pour faire face à ce problème, j'ai exploré fin 2023 une solution basée sur pgBackRest : Implémenter un POC de pgBackRest.
Je suis plus ou moins arrivé au bout de ce POC mais je n'ai pas été satisfait du résultat.
Je n'ai pas réussi à configurer pgBackRest en "pure Docker sidecar".
De plus, j'ai trouvé la restauration du backup difficile à exécuter.

Un élément a changé depuis septembre 2024. Comme je le disais dans cette note 2024-11-03_1151, la version 17 de PostgreSQL propose de nouvelles options de sauvegarde :

  • l'outil pg_basebackup qui permet de réaliser les sauvegardes incrémentales,
  • et un nouvel utilitaire, pg_combinebackup, qui permet de reconstituer une sauvegarde complète à partir de sauvegardes incrémentales.

Cette nouvelle méthode semble apporter certains avantages par rapport aux solutions basées sur WAL comme pgBackRest ou barman.

Une consommation d'espace réduite :

In this mailing list thread on the Postgres-hackers mailing list, Jakub from EDB ran a test. This is a pgbench test. The idea is that the data size doesn't really change much throughout this test. This is a 24 hour long test. At the start the database is 3.3GB. At the end, the database is 4.3GB. Then, as it's running, it's continuously running pgbench workloads. In those 24 hours, if you looked at the WAL archive, there were 77 GB of WAL produced.

That's a lot of WAL to replay if you wanted to restore to a particular point in time within that timeframe!

Jakub ran one full backup in the beginning and then incremental backups every two hours. The full backup in the beginning is 3.4 GB, but then all the 11 other backups are 3.5 in total, they're essentially one 10th of a full backup size.

source

Une vitesse de restauration grandement accélérée :

A 10x time safe

What Jakub tested then was the restore to a particular point in time. Previously, to restore to a particular point in time would take more than an hour to replay the WAL versus in this case because we have more frequent, incremental backups, it's going to be much, much faster to restore. In this particular test case 78 minutes compared to 4 minutes. This is a more than a 10 times improvement in recovery time. Of course you won't necessarily always see this amount of benefit, but I think this shows why you might want to do this. It is because you want to enable more frequent backups and incremental backups are the way to do that.

source

Nombre 2024 j'ai passé un peu de temps à étudier les solutions de backup qui utilisent la nouvelle fonctionnalité de PostgreSQL 17, mais je n'avais rien trouvé

Je viens à nouveau de chercher dans les archives de Postgre Weely, sur GitHub, sur le forum de Restic, etc., et je n'ai rien trouvé d'intéressant.

#JaiDécidé de prendre les choses en main et de faire évoluer le projet restic-pg_dump-docker pour y ajouter le support du backup incrémental de PostgreSQL 17.

Voir : Projet 23 - "Ajouter le support pg_basebackup incremental à restic-pg_dump-docker".

Journal du dimanche 03 novembre 2024 à 11:51 #postgresql, #backup, #JaiDécouvert

Avec la sortie de la version 17 de PostgreSQL, de nouvelles options de sauvegarde sont désormais disponibles : l'outil pg_basebackup (https://www.postgresql.org/docs/17/app-pgbasebackup.html) permet de réaliser les sauvegardes incrémentales, et un nouvel utilitaire, pg_combinebackup, permet de reconstituer une sauvegarde complète à partir de sauvegardes incrémentales.

J'ai lu les articles suivants de Robert Haas, créateur de ces nouvelles fonctionnalités :

J'en ai profité aussi pour lire :

J'ai trouvé tous ces articles très intéressants, j'y ai appris beaucoup de choses.

Je me demande quel impact ces fonctionnalités auront ou ont déjà sur les outils existants comme pgBackRest, barman, et wal-g.

Autres ressources :

Impact sur pgBackRest ?

Voici ce que j'ai trouvé dans le projet pgBackRest.

We are aware of what's been committed to PG17.

-- from

Je comprends d'après ce commentaire que les auteurs de pgBackRest sont bien au courant des avancées de PostgreSQL 17.

Issue : WAL summarizer in pg 17 and incremental backups in pgbackrest ?.

We already support page-level (we call it block-level) incremental since v2.46 and it works for all versions of PostgreSQL supported by pgBackRest (>= 9.4), see https://pgbackrest.org/user-guide.html#backup/block.

We are planning to use the WAL summarizer to help us pick more optimal block sizes and cross-check timestamps but we are waiting for it to be a bit more stable. Also, the WAL summarizer output uses a lot of memory and is not the best fit for large databases with a lot of changes. We have some ideas on how to make that more efficient but have not had time to pursue it yet.

D'après ce commentaire, je pense avoir compris que les nouvelles fonctionnalités de backup incrémental de PostgreSQL 17 ne sont d'aucune utilité pour pgBackRest, qui implémente déjà cette fonctionnalité de manière efficace 🤔.

Impact sur barman ?

La version 3.11.0 de barman intègre des fonctionnalités liées aux nouvelles fonctionnalités de PostgreSQL 17.

Impact sur wal-g

J'ai n'ai trouvé aucune mention de pg_combinebackup, ni de pg_basebackup incremental dans le repository de wal-g.


J'ai l'impression qu'il est possible d'utiliser directement pg_basebackup pour effectuer des sauvegardes incrémentales de bases de données PostgreSQL. Cependant, je crains que cette idée soit un peu naïve.

Vers la fin de 2023, j'ai commencé à implémenter un POC de pgBackRest : https://github.com/stephane-klein/backlog/issues/322. J'ai pu réaliser une simulation complète de son utilisation dans ce dépôt : poc-pgbackrest. Cependant, je n'ai pas conservé un souvenir précis des raisons pour lesquelles mon expérience utilisateur n'a pas été satisfaisante, ce qui m'a dissuadé de déployer pgBackRest en production.

Après avoir constaté que barman intègre la fonctionnalité increment de pg_basebackup, j'ai envie de tester barman.
